| Material: |
Stainless steel/Aluminum |
| Bottle Holder: |
Stainless steel, bottle bar |
| Arrangement of the hooks: |
In line with each other |
| Type of height adjustment: |
Screw height adjustment |
| Maximum length/height: |
1,640 mm (5.38057′) |
| Minimum length/height: |
1,150 mm (3.77296′) |
| Parallel shift: |
Approximately 350 |
| Inner tube diameter: |
Ø 18 mm (0.70866″) |
| Outer tube diameter: |
Ø 25 mm (0.98425″) |
| Length of outer tube: |
600 mm (1.96850′) |
| Equipment: |
2 x 45 ° angles with medical rail clamp and wall support, for assembling onto medical rails 25 mm (0.98425″) x 10 mm (0.39370″) |
| Total load capacity (kg): |
4 kg (8.81 lbs) |
| Load capacity per system (kg): |
4 kg (8.81 lbs) |
| Load capacity per hook (kg): |
2 kg (4.41 lbs) |
